Three Phase Electric Meter


Three Phase Electric Meter

We are counted amongst Exporters and Suppliers of Three Phase Electric Meter. The product displays KVAH/KWH units on both MAIN (EB) & DG.

Features
  • System provides true energy and load management.
  • Remote meter reading.
  • Deficiency metering (Energy recording in absence of neutral).
  • Supports “Forwarded” energy registration in case of current reversal.
  • Load limit on MAIN (EB) & DG can be assigned independently.
  • World class Gruner Relays for overload auto-cut.
  • RS485 port for communication with GPRS modem/Server.
  • Monitoring of energy data of the consumer meters located all over the township is achieved from a centralized location.
  • Meters can be recharged through, Internet or from the site office.
  • Provides input/output power consumption analysis for controlling line loss.
  • Optional in house display unit with reset button.
  • Advanced tamper & fraud detection capability/SMS alerts for tamper detection.
  • Prepayment scheme can be activated or de-activated.
  • Auto High (275v)/low(140v) voltage cut off to protect electronic consumer appliances

Technical Specifications
  • Input Voltage : 440V 3 Phase
  • Max Current : 60A per Phase
  • Frequency : 40 ~ 60 HZ
  • Accuracy : Class 1.0

Mechanical
  • Dimensions (W*H*D) : 170 x 220 x 90 mm
  • Weight : 1.5 Kgs
  • Enclosure : Polycarbonate
  • Sealing : Tamper Proof Polycarbonate Seal

Electrical
  • Connection Type : Direct connected
  • Wiring Configuration : Three phase, Four wire
  • Voltage Range : 170~300 V A C
  • Current Range : 10~60 A
  • Accuracy : Class 1.0
  • Frequency : 50 HZ ± 10%
  • Burden : < 10 VA

Environmental
  • Ingress Protection : IP51
  • Insulation Class : Double Encaged
  • Impulse Withstand : 6 KV for 1.2/50 μs
  • Temperature : Operating -10~55 c , Storage -10~65 c
  • Humidity : Upto 95% non-condensing

Compliance : IS 13779
Communication : RS485 protocol
